Unitech MS912 Quick Guide

- 25 - - 26 -
Data Output Method
You may output data ONLY when memory is enabled (page 24).
To output stored data via Wireless, please do the following:
1. Scan [WIRELESS]
2. Scan [OUTPUT DATA]
To output stored data via USB-VCP, please do the following:
1. Install VCP driver (available on CD)
2. Connect the scanner & host with USB cable
3. Scan [USB-VCP]
4. Save data as .csv by “Covert to CSV.exe” (available on CD)
*
. R013$
*.R013$*
USB-VCP
. R014$
*.R014$*
WIRELESS
OUTPUT DATA
For memory version only
. R003$
*.R003$*
OUTPUT DATA
DATA FORMAT
Example:
To change Data Format to
<Item No.>, <Barcode Data>, <Date>, <Time>
1. Scan [ Data Format ]
2. Scan [1], [4], [2], [3] on page 9.
3. Scan [
Data Format ]
The default Data Format is
<Barcode Data> only
below are items and their setup codes:
For memory version only
Default is comma ( , ) . You may replace it with any alphanumeric
characters from the full ASCII table in User’s Manual (on CD).
Example: To change Field Separator to Semicolon ( ; )
1. Scan [
Field Separator ]
2. Scan [ ; ] from the full ASCII table.
3. Scan [
Field Separator ]
. R010$
*.R010$*
FIELD SEPARATOR
. R011$
*.R011$*
DATA FORMAT
1
2
Item No.
Date
Code Item Code Item
3
4
Time
Barcode Data

Unitech MS912 Specifications

General

Type	Handheld bar code reader
Sensor type	CCD / CMOS
Scanner type	1D
Read rate (max)	240 reads/s
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 32, Code 39, Code 93, EAN-8, MSI
2D (matrix & stacked) barcodes supported	Not supported
Wireless range	10 m
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Product color	Black, White
Housing material	ABS synthetics
Battery voltage	3.7 V
Power source type	Battery
Number of reads per charge	5000
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 85 %
Cables included	USB

Weight and Dimensions

Depth	72 mm
Width	30 mm
Height	20 mm
Weight	30.2 g
