Mode.
2. Install Bluetooth Connect.apk, which is available on CD.
Note: Before installation, enable ‘Unknown Sources” in Android
Authority.
3. Enable [BluetoothConnect] in the Language & Keyboard
setting window and choose [BluetoothConnect] as Input
Method.
4. Click [Connect] and you will be able to connect the scanner.
Note: BluetoothConnect needs to be installed only when you have
U NO U wireless input application on your Android device. Android 2.x
devices can work with MS912 in the SPP mode ONLY. The SPP
mode or/and the HID mode are not definitely compatible with each
version of Android OS, and thus depends on the Android-based
hardware specifications defined by the Android device
manufacturers.
To get the detailed example of SPP setting, refer to Appendix 2.
Smartphone/ Tablet PC Connection (iOS)
1. Pair with the scanner via [HID]; see topic
“Connecting via Human Interface Device (HID)
Mode”.
2. Scan the numeric barcode according to the
pincode generated by the Bluetooth
application.
3. The scanner will beep twice to verify the
successful connection.
Note: No special application needs to be installed
when the scanner is connected to iOS smartphone/
tablet PC via HID mode.
To get the detailed example of HID setting, refer to Appendix 2.
Set Bluetooth Device ID
To customize your own Bluetooth device (MS912) name for the wireless scanner, please follow
below steps:
STEP 1

Unitech MS912 Specifications

General

Type	Handheld bar code reader
Sensor type	CCD / CMOS
Scanner type	1D
Read rate (max)	240 reads/s
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 32, Code 39, Code 93, EAN-8, MSI
2D (matrix & stacked) barcodes supported	Not supported
Wireless range	10 m
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Product color	Black, White
Housing material	ABS synthetics
Battery voltage	3.7 V
Power source type	Battery
Number of reads per charge	5000
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 85 %
Cables included	USB

Weight and Dimensions

Depth	72 mm
Width	30 mm
Height	20 mm
Weight	30.2 g
