Unitech MS912 User Manual

40
Unitech electronics co., ltd.
5F., No.135, Ln. 235, Baoqiao Rd., Xindian Dist., New Taipei City 231, Taiwan (R.O.C.)
 Tel: + 886 2 89121122  Fax: +886 2 89121810  website: www.ute.com
SETTING PROCEDURE
MIN / MAX LENGTH
STEP 1 - Scan: MIN LENGTH/ MAX LENGTH
STEP 2 - Scan: Two digits from Appendix.
STEP 3 - Scan: MIN LENGTH/ MAX LENGTH
Please note that when Min Length and / or Max Length are enabled, the scanner will only read bar codes that fall into those length parameters.
Bar codes shorter or longer than specified will not be read. The default lengths for these are indicated in parentheses under the Min and Max
bar codes for each symbology.

Unitech MS912 Specifications

General

Type	Handheld bar code reader
Sensor type	CCD / CMOS
Scanner type	1D
Read rate (max)	240 reads/s
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 32, Code 39, Code 93, EAN-8, MSI
2D (matrix & stacked) barcodes supported	Not supported
Wireless range	10 m
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Product color	Black, White
Housing material	ABS synthetics
Battery voltage	3.7 V
Power source type	Battery
Number of reads per charge	5000
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 85 %
Cables included	USB

Weight and Dimensions

Depth	72 mm
Width	30 mm
Height	20 mm
Weight	30.2 g
