MSR120 Programmer’s Manual UDN PM010, Rev. 1.1
Section 2 -- Configurations 2003/1/21
Section 2 Configurations
This section shows the dimensions, accessories and setup for the MSR120.
!"
Dimensions of MSR120
Figure 2-1 Dimensions of MSR120
!"Accessories of MSR120
The following accessories should be supplied along with MSR120. Make sure all the following accessories are
contained in your package.
1. Signal cable (USB Connector, 1.7M)
2. Programmer’s manual
!"
Installation
1. Power off your PC system.
2. Connect PC and MSR120 as below.
Page 2-1
Proprietary and Confidential Total 36 pages
To Next Page
