MSR120 Programmer’s Manual UDN PM010, Rev. 1.1
Section 5 – Configuration Commands 2003/1/21
09h 00h 03h 42h 5Ah 44h 56h Disable
09h 00h 03h 42h 5Ah 45h 57h Enable (default)
TKx (54h 4Bh x) ! Set Transmitting Data Tracks
x is an ASCII number (1-7)
Table 5-5. Transmit Tracks Setting
ASCII
Command Form (Hex)
Transmit Tracks
1 09h 00h 03h 54h 4Bh 31h 24h Track 1
2 09h 00h 03h 54h 4Bh 32h 27h Track 2
3 09h 00h 03h 54h 4Bh 33h 26h Track 1 & 2
4 09h 00h 03h 54h 4Bh 34h 21h Track 3
5 09h 00h 03h 54h 4Bh 35h 20h Track 1 & 3
6 09h 00h 03h 54h 4Bh 36h 23h Track 2 & 3
7 09h 00h 03h 54h 4Bh 37h 22h Track 1, 2 & 3 (default)
AAx (41h 41h x) ! Set Address
1 x is a binary byte (00h-0Fh)
2 Set address 00h: <09h 00h 03h 41h 41h 00h 0Ah>
SAx (53h 41h x) ! Self -Arm Mode Enable/Disable
x = E(45h enable) or D(44h disable)
Table 5-6. Self-Arm Mode Setting
Command Form (Hex)
Self-Arm Mode
09h 00h 03h 53h 41h 44h 5Ch Disable
09h 00h 03h 53h 41h 45h 5Dh Enable (default)
SPx (53h 50h x) ! Set Track Separator
1 x = Hex Code
2 x = 00h means do not send separator code
Table 5-7. Track Separator Setting
Command Form (Hex)
Track Separator
09h 00h 03h 53h 50h 00h 09h Disable (default)
Example of Track Separator Setting
09h 00h 03h 53h 50h 0Dh 04h 0Dh, <CR>
09h 00h 03h 53h 50h 2Bh 22h 2Bh, <+>
09h 00h 03h 53h 50h 3Bh 32h 3Bh, <;>
Page 5-2
Proprietary and Confidential Total 36 pages
