Unitech MSR120 User Manual

MSR120 Programmer’s Manual UDN PM010, Rev. 1.1
Section 3 -- Technical Specification 2003/1/21
!"
USB Connector Termination Assignment
Table 3-2. Connector Assignment
Contact
Number
Signal
Name
Typical Wiring
Assignment
1
Vbus
Red
2
D-
White
3
D+
Green
4 GND Black
Shell Shield Drain Wire
!"
Communication
The interface receives and transmits serial bit stream at voltage levels compatible with the USB specification.
Transmission Protocol
The user may select from three different protocols: Protocol 0, 1, and 2.
Upon reset, the reader sends the power-on response “:”, depending upon the configuration setting. The reader then
configures itself to the protocol of the first command from the host. From this point on, the protocol is
unchangeable until a reset occurs.
Protocol 0
In Protocol 0, all characters are transmitted and received using exactly the characters listed in section 4. There are
no headers and Block Check Characters (BCC). Protocol 0 presumes no transmission errors. If the host detects an
error, it may request a retransmission.
Table 3-3. Example for Protocol 0
Host Command Reader Response Comment
P Ready to read
^ Reader ACK
Protocol 1
In Protocol 1, all messages are preceded by the ASCII character <STX> and terminated with the ASCII character
<ETX>, followed by a one byte <BCC>. <BCC> is an XOR of the 7 data bits, excluding parity, of each character
in the entire message, including <STX>.
Format: <STX><MESSAGE><ETX><BCC>
where STX=02Hex and ETX=03Hex.
Table 3-4. Example for Protocol 1
Page 3-3
Proprietary and Confidential Total 36 pages
