29
Copyright 2011 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
Appendix A
System Specification
CPU
Samsung 6410, 667Mhz
Processor/Memory
Memory
SDRAM: 256 MB
Flash ROM: 256 MB
OS Microsoft Windows CE 6.0 Professional Plus
Keypad
Six-key [Clock In (F1)Clock Out (F2)Break In (F3)Break Out
(F4)Enter (Yes) Escape (No)]
Display
5.7-inch 480 x 640 VGA, Color Transflective TFT with Touch Screen
& backlight
Communication and I/O
RS232/485
USB 1.1 host
802.11b/g (optional)
Output relays x 2 / Digital inputs x 2
Ethernet connection
Power over Ethernet (Optional)
Multimedia
Camera: 2.0 megapixel CMOS camera
Audio output: 0.8 W speaker
Microphone input
Expansion Slot SD slot for memory expansion
Power Source Battery Lithium-lon @ 7.4V 1400mAh main battery pack
Weight 700g
Enclosure
Dimension Approximately 305.4mm x 212.9mm x 48.2mm Max.
Operating temperature - 10 to 50 (14ºF~ 122ºF)℃℃
Storage temperature -20 to ℃ 70 (℃ -4ºF~ 158ºF)
Environmental
Relative Humidity 10~ 90 % RH non-condensing
Certification CE, FCC, NCC, VCCI, RoHS compliant
Software
Visual Studio
C++, C#, VB.NET
Reader
EM, 125 kHz
HID, 125 kHz
Mifare, 13.56MHz
Barcode reader, reading UPC/EAN/JAN, Code39, code 128,
CODABAR
