Unitest Hexagon 110 - Page 49

DC Voltage
Measurement Resolution Accuracy Overload Protection
Range
400,0 mV 0,1 mV ± (0,3% rdg.+4D)
4,000 V 0,001 V ± (0,5% rdg.+3D)
40,00 V 0,01 V ± (0,5% rdg. +3D) 1050 Vrms
400,0 V 0,1 V ± (0,5% rdg. +3D) 1450 Vpeak
1000 V 1 V ± (1% rdg. + 4D)
NMRR: >50 dB (50/60 Hz)
CMRR: >120 dB (50/60 Hz, Rs=1kOhm)
Input impedance: 10 MOhm,
30 pF typical (1000 MOhm for 400-mV range)
AC Voltage (50...500 Hz)
Measurement Resolution Accuracy
Range
400 mV* 0,1 mV ± (4,0% rdg. + 5 D)
4,000 V 0,001 V ± (1,5% rdg. + 5 D)
40,00 V 0,01 V ± (1,5% rdg. + 5 D)
400,0 V 0,1 V ± (1,5% rdg. + 5 D)
1000 V 1 V ± (4,0% rdg. + 5 D)
Overload Protection: 1050 Vrms, 1450 Vpeak
CMRR: >60 dB (0...60 Hz, Rs=1kOhm)
Input impedance: 10 MOhm, 30 pF typical
* Selection by RANGE button manually and is specified
from AC 10 mV.
49
Technical Data
ENGLISH
