Frequency (sinus shape)
Measurement Resolution Accuracy Overload
Range Protection
5,000 Hz... 0,001 Hz ± (0,5% rdg. + 4D) 600 Vrms
1 MHz 50/60Hz /DC
Sensitivity:
Measurement range 5 Hz...100 kHz (> 1,3 Vp)
Measurement range 100 kHz...500 kHz (> 2,2 Vp)
Measurement range 500 kHz...1 MHz (> 4,2 Vp)
Sampling rate: 2 measurements/s
Resistance
Measurement Resolution Accuracy Overload
Range Protection
400,0 Ω 0,1 Ω ± (0,8% rdg.+6 D)
4,000 kΩ 0,001 kΩ ± (0,6% rdg.+4 D)
40,00 kΩ 0,01 kΩ ± (0,6% rdg.+4 D) 600 Vrms
400,0 kΩ 0,1 kΩ ± (0,6% rdg.+4 D) 50/60Hz /DC
4,000 MΩ 0,001 MΩ ± (1,0% rdg.+4 D)
40,00 MΩ 0,01 MΩ ± (2,0% rdg. +4 D)
Test voltage <0,4 V DC
Acoustic continuity test
Signal sound: approx. 20...60
Ω (response time: < 1 ms)
Diode test
Measurement Test Current Test Voltage Overload Protection
Range - (typ.)
1,000 V 0,25 mA < 1,6 V DC 600Veff
50/60Hz/DC
Capacity
Measurement Resolution Accuracy Overload
Range Protection
500,0 nF 0,1 nF ± (3,5% rdg.+6 D)
5,000 µF 0,001 mF ± (3,5% rdg.+6 D)
50,00 µF 0,01 mF ± (3,5% rdg.+6 D) 600 Vrms
500,0 µF 0,1 mF ± (3,5% rdg.+6 D) 50/60Hz /DC
3000 µF 1 mF ± (3,5% rdg.+6 D)
50
Technical Data
