DC Current
Measurement Resolution Accuracy Burden Voltage
Range
400,0 µA 0,1 µA ± (2,0% rdg.+5 D) 0,15 mV/mA
4000 µA 1 µA ± (1,2% rdg.+3 D) 0,15 mV/mA
40,00 mA 0,01 mA ± (2,0% rdg.+5 D) 3,3 mV/mA
400,0 mA 0,1 mA ± (1,2% rdg.+3 D) 3,3 mV/mA
4,000 A 0,001 A ± (2,0% rdg.+5 D) 0,03 V/A
10,00 A* 0,01 A ± (1,2% rdg.+3 D) 0,03 V/A
*10 A continuous, 20 A for max. 30 s with 4 min
cooling-down
Overload protection: 0,63A/ 500V FF
12,5A/ 500V FF
AC current (50...500 Hz)
Measurement Resolution Accuracy Burden Voltage
Range
400,0 µA 0,1 µA ± (2,0% rdg.+6 D) 0,15 mV/mA
4000 µA 1 µA ± (1,5% rdg.+4 D) 0,15 mV/mA
40,00 mA 0,01 mA ± (2,0% rdg.+6 D) 3,3 mV/mA
400,0 mA 0,1 mA ± (1,7% rdg.+4 D) 3,3 mV/mA
4,000 A 0,001A ± (2,0% rdg.+6 D) 0,03 V/A
10,00 A* 0,01 A ± (1,8% rdg.+4 D) 0,03 V/A
* 10 A continuous, 20 A for max. 30 s with 5 min
cooling-down
Overload protection: 0,63A/ 500V FF
12,5A/ 500V FF
Temperature (only for Hexagon 120)
Measurement Accuracy Overload Protection
Range
-20...300°C ± (2% rdg. + 3°C) 600 Vrms 50/60Hz /DC
0...572°F ± (2% rdg. + 6°F)
The thermocouple accuracy is not considered.
51
Technical Data
ENGLISH
