Capacity
Measurement Range........................Accuracy
50,00 nF ..........................................± (0,8% rdg. + 3 D)
500,0 nF ..........................................± (0,8% rdg. + 3 D)
5,000 µF ..........................................± (1,0% rdg. + 3 D)
50,00 µF ..........................................± (2,0% rdg. + 3 D)
500,0 µF ..........................................± (3,5% rdg. + 5 D)
9999 µF ..........................................± (5,0% rdg. + 5 D)
Overload protection: ........................600 V ACrms /DC Hexagon 710
........................................................1050 Vrms, 1450 Vss Hexagon 720
Frequency (sinus-shape)
Measurement Range........................Accuracy
5,0000 Hz...200,000 kHz ................± (0,002% rdg. + 4 D)
Sensitivity:
Measurement range 500 mV (min. 0,1 V)
Measurement range 5 V (min. 1 V)
Measurement range 50 V (min. 10 V)
Measurement range 500 V (min. 100 V)
Measurement range 1000 V (min. 900 V)
Overoald protection: ......................600 V ACrms /DC Hexagon 710
........................................................1050 Vrms, 1450 Vss Hexagon 720
Frequency (rectangular shape, logic)
Measurement Range........................Accuracy
5,0000 Hz...200,000 kHz ................± (0,002% rdg. + 4 D)
Sensitivity: ......................................2,5 Vs rectangular shape
Overload protection: ........................600 V ACrms /DC Hexagon 710
........................................................1050 Vrms, 1450 Vss Hexagon 720
Scanning degree (%)
Measurement ..................................Range Accuracy
0,1%...99,99% ................................± (3 D/kHz + 2 D)
Input frequency: ............................5 Hz...500 kHz, 5 V logic
Overload protection: ........................600 V ACrms /DC Hexagon 710
........................................................1050 Vrms, 1450 Vss Hexagon 720
