DC Current
Measurement Range Accuracy Apparent Voltage Overload Protection
500,00 mA ± (0,15% rdg. + 20 D) 0,15 mV/mA
5000,0 mA ± (0,1% rdg. + 20 D) 0,15 mV/mA 0,63 A / 500 V (710)
50,000 mA ± (0,15% rdg. + 10 D) 3,3 mV/mA 1 A / 600 V (720)
500,00 mA ± (0,1% rdg. + 20 D) 3,3 mV/mA
5,0000 A ± (0,5% rdg. + 10 D) 0,03 V/A 12,5 A / 500 V (710)
10,000 A* ± (0,5% rdg. + 20 D) 0,03 V/A 15 A / 1 kV (720)
* 10 A continuous, 20 A for max. 30 s including 5 min cooling down
AC, AC/DC Current
Range Hexagon 710 Hexagon 720 Apparent Voltage Overload Protection
50...60 Hz
500,00 mA 0,15 mV/mA 0,63 A / 500 V
5000,0 mA 0,15 mV/mA (Hexagon 710)
50,000 mA ± (1,0% rdg. + 40 D) ± (0,5% rdg. 3,3 mV/mA 1 A / 600 V
500,00 mA + 50 D) 3,3 mV/mA (Hexagon 720)
5,0000 A 0,03 V/A 12,5 A / 500 V (710)
10,000 A* 0,03 V/A 15 A / 1 kV (720)
40Hz..1kHz
500,00 mA 0,15 mV/mA 0,63 A / 500 V
5000,0 mA 0,15 mV/mA (Hexagon 710)
50,000 mA ± (1,0% rdg. + 40 D) ± (0,7% rdg. 3,3 mV/mA 1 A / 600 V
500,00 mA + 50 D) 3,3 mV/mA (Hexagon 720)
5,0000 A 0,03 V/A 12,5 A / 500 V (710)
10,000 A 0,03 V/A 15 A / 1 kV (720)
1kHz..10kHz
500,00 mA 0,15 mV/mA 0,63 A / 500 V
5000,0 mA ± (2,0% rdg. 0,15 mV/mA (Hexagon 710)
50,000 mA not specified + 50 D) 3,3 mV/mA 1 A / 600 V
500,00 mA 3,3 mV/mA (Hexagon 720)
5,0000 A not specified 0,03 V/A 12,5 A / 500 V (710)
10,000 A not specified 0,03 V/A 15 A / 1 kV (720)
* 10 A continuous, 20 A for max. 30 s including 5 min cooling down
74
Technical Data
