Control Room Unit for Model 9100 Carbon Monoxide Monitors User Guide
8
CO Reading Large text display
Display units (ppm or mg/m3) match those selected on the
Model 9100
Parameters Parameters page 1
Parameters page 2
Parameters page 3
Parameters page 4
Parameters page 5
Faults List of active faults
Calibration Start Cal Check
Start Zero Cal
Setup Set Modbus Address
O/P Range 1
O/P Range 2
Alarm 1
Alarm 2
Faults
Any faults indicated by the Model 9100 can be viewed on the Faults display. If no
faults are found, the display will show “No Faults”. If faults are present, the display will
indicate the relevant fault message. Multiple faults can be viewed by scrolling left or
right using the touch screen.
Menu Tree
