User Guide Control Room Unit for Model 9100 Carbon Monoxide Monitors
1
Introduction
Applications and Usage
The control room unit is intended for use with the Land Model 9100 Carbon Monoxide
Monitor. The control room unit is not suitable for use with any other equipment.
The control room unit must be protected from dust and moisture. However, the front
panel is fully weatherproof to IP 65 once it has been installed into a suitable panel or
enclosure.
A 5 A external circuit breaker must be provided.
input/output module
(optional)
control panel
cable connector
power supply
(optional)
Model 9100
Carbon Monoxide monitor
