Control Room Unit for Model 9100 Carbon Monoxide Monitors User Guide
2
260 (10.24)
206 (8.11)
155 (6.1)
72 (2.8)
95.5
(3.72)
49
(1.92)
gasket
Dimensions of Control Room Unit
260 (10.24)
earth
ø4 (0.15)
5 (0.19)
35 (1.38)
126 (4.96)
155 (6.1)
Dimensions of Cutout
earth assembly
supplied with
control room unit
front view
The diagram shows the
optional input/output unit
installed.
