Specifications
39
Analog-To-Digital Converter Section
Note: all specifications are typical performance unless otherwise noted. Unless otherwise noted, all
specifications are 20 Hz-20 kHz, minimum gain, maximum level, 24 bits, all switches in neutral or off
mode, 100% solid state, -1 dBFS output.
Microphone Input
THD+N (-1 dBFS)
-100 dB (0.001%)
SNR (A-Wt)
110 dB
Dynamic Range (-60 dBFS, A-wt)
110 dB
Frequency Response
+0.1/-0.15 dB
Stereo Phase
< 0.3 deg
Line Input (Ch 1-4)
THD+N (-1 dBFS)
-100 dB (0.001%)
SNR (A-Wt)
110 dB
Dynamic Range (-60 dBFS, A-Wt)
110 dB
Frequency Response
+0.1/-0.15 dB
Stereo Phase
< 0.3 deg
Line Input (Ch 5-8)
THD+N (-1 dBFS)
-103 dB (0.0007%)
SNR (A-Wt)
117 dB
Dynamic Range (-60 dBFS, A-Wt)
117 dB
Frequency Response
±0.1 dB
Stereo Phase
< 0.5 deg
16-Bit Mode
Dither Type
Triangular
Sample Resolution
16 bits
THD+N (-1 dBFS, 16 bits)
-93 dB (0.0022%)
SNR (A-Wt)
98 dB
Dynamic Range (-60 dBFS, A-Wt)
98 dB
(Continued)
