Universal Audio 4-710d User Manual

Specifications
40
Digital Output Section
Digital Output Formats
AES/EBU
8 channels, 44.1-192kHz, single wire
ADAT Optical
44.1-48kHz:
Port 1 = channel 1-8
Port 2 = channel 1-8 (duplicate out)
88.2-96Khz (S/MUX™):
Port 1 = channel 1-4
Port 2 = channel 5-8
176.4-192kHz (S/MUX™):
Port 1 = channel 1-2
Port 2 = channel 3-4
Bit Depths
24-Bit
16-Bit (dithered)
Clock Options
Internal (crystal)
44.1, 48, 88.2, 96, 176.4, 192 kHz
Word Clock
44.1, 48, 88.2, 96, 176.4, 192 kHz
Lock range ±3%
Optional termination (75 ohms)
A/D Metering
Bottom segment: Green, -37 dB to -6 dB
Top segment: Yellow, -6 dB to -1 dB
Top segment: Red, -1 dB to Clip
Connector Types
Digital Output Formats
External Connections (rear panel)
8 x XLR Female Line in, Mic in (channel 1-4)
4 x XLR Male Line out (channel 1-4)
12 x ¼” TRS Female (ch 1-4 send, return, line in 5-8)
2 x Toslink out (ADAT Optical output 1-8)
2 x BNC 75Ω (Word Clock in, out)
1 x DB-25 (AES/EBU Tascam pin-out, ch 1-8)
External Connections (front panel)
4 x ¼” TRS Female (channel 1-4 Hi-Z in)
Mechanical and Power
Power
AC Requirements
100VAC - 240VAC, 50/60 Hz, auto-switching
Maximum Power Consumption
0.525 A @ 120 VAC (60W)
Power Connector
Detachable IEC power cable
Mechanical
Dimensions
2U Rack
19” x 3.5” x 12” (W x H x D) inches
48.2 x 8.9 x 30.5 (W x H x D) cm
Weight
11.5 lbs (5.2 kg)

Universal Audio 4-710d Specifications

General

Type	Pre-amp
Proper use	Concert/Studio
Product color	Silver
