Universal Robots UR3e

All rights reserved 179 Service Manual e-Series (EN) 1.1.8
Base with Robot Arm cable for UR10e/UR16e –122080
Base with Robot Arm cable for UR10e/UR16e –122080
NO.
QTY.
DESCRIPTION
PART NUMBER(S)
PAGE NO.
1
1
Flat ring for size 4
103700
149
2
1
Wear ring for size 4
103700
149
3
1
Bracket connection incl. bolts and seals size 4
N/A
N/A
5
1
Base incl. cable, size 4
N/A
N/A
6
1
Plug for Base
N/A
N/A
