ENGINE SPECIFICATIONS
Model 25XP
Model 35 Allowable Limit
0.05 mm 0.05 mm
(0.0020 in.)
(0.0019 in.)
-
0.6 to 0.8 mm
0.6 to 0.8 mm
(0.0236 to 0.0315 in.) (0.0236 to 0.0315 in.)
-
1.15 to 1.30 mm 1.15 to 1.30 mm
(0.0453 to 0.0512 in.) (0.0453 to 0.0512 in.)
-
1.05 to 1.15 mm
1.05 to 1.15 mm
(0.0413 to 0.0453 in.)
(0.0413 to 0.0453 in.)
-
0.2 mm
0.2 mm
(0.0079 in.)
(0.0079. in.)
-
3.00 MPa
3.09 MPa 23.7 kgf/cm2
(29.5 kgf/cm2, 427 psi)
(31.5 kgf/cm2, 448 psi)
(337 psi)
-
-
-
0.145 to 0.185 mm
0.145 to 0.185 mm
(0.006 to 0.007 in.) (0.006 to 0.007 in.)
-
2.1 mm
2.12 mm
(0.083 in.) (0.0835 in)
-
0.785 rad. 0.785 rad.
(45°)
(45°)
-
0.785 rad. 0.794 rad.
(45°)
(45.5°)
-
0.9 to 1.1 mm
0.9 to 1.1 mm 1.3 mm
(0.035 to 0.043 in.)
(0.035 to 0.043 in.)
(0.051 in.)
0.035 to 0.065 mm
0.035 to 0.065 mm
0.1 mm
(0.0014 to 0.0026 in.)
(0.0014 to 0.0026 in.)
(0.004 in)
6.960 to 6.975
6.960 to 6.975 mm
(0.2740 to 0.2746 in.) (0.274 to 0.2746 in.)
-
7.010 to 7.025 mm 7.010 to 7.025 mm
(0.2759 to 0.2765 in.) (0.2759 to 2.2765 in.)
-
0.35 rad. (20°)
0.35
rad. (20°)
before TOe
before TOe
-
0.79 rad. (45°)
0.79
rad. (45°)
after TOe after TOe
-
0.87 rad. (50°)
0.87 rad. (50°)
before TOe
before TOe
-
0.26 rad. (15°)
0.26 rad. (15°)
after TOe
after TOe
-
35.1 to 35.6 mm
35.1 to 35.6 mm
34.8 mm
(1.382 in. to 1.402 in.) (1.382 to 1.402 in.)
(1.37 in.)
1.3 mm
1.3 mm
(0.051 in.)
(0.051 in.)
-
74 N/31 mm 74 N/31 mm
63 N/31 mm
7.5 Kgf/cm2
7.5 Kgf/cm2
6.4 Kgf/cm2
(16.5 Ibs, 1.22 in.)
(16.5 Ibs, 1.22 in.)
(14.1 Ibs, 1.22 in.)
21
