Technical specications
Operating voltage 24 VAC +/- 10% Class II
circuits only
Maximum load 1.3 Amps at 24VAC or equivalent
of 6 thermal valve actuators
Air display range 32°F to 95°F (0°C to 35°C)
Floor display range 32°F to 140°F (0°C to 60°C)
Air setting range 34°F to 86°F (1°C to 30°C)
68°F (20°C) default
Floor setting range 34°F to 95°F (1°C to 35°C)
68°F (20°C) default
Air maximum setting Adjustable to 86°F (30°C)
Floor maximum setting Adjustable to 95°F (35°C)
CAN ICES-3 (B)/NMB-3(B) compliance
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed in accordance
with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause interference to radio or television
reception, which can be determined by turning the equipment
off and on, the user is encouraged to try and correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment to a different circuit from that to which
the receiver is connected
• Consult the dealer or an experienced radio/TVG technician
for help
Setpoint limits settings
Minimum range 38°F (3°C) to maximum limit setting
50°F (10°C) default
Maximum range Minimum limit setting to 99°F (37°C)
86°F (30°C) default
Floor sensor 10K J curve, 250 ft. maximum with
18 AWG
Units User-congurable Fahrenheit or Celsius
Memory Permanent for all settings and modes
Resolution 1°F (0.5°C) displayed, 0.25° calculated
Temperature
ranges
Shipping and storage: 14°F to 158°F
(-10°C to 70°C)
Operation: 32°F to 104°F (0°C to 40°C)
Humidity 20 to 90% non-condensing
Size 5.39" (136.91mm) H x 3.22"
(81.79mm) W x 0.63" (16mm) D
Sensor temperature vs. resistance table
Temperature Resistance
°F °C Ω
-50 -46 490,813
-45 -43 405,710
-40 -40 336,606
-35 -37 280,279
-30 -34 234,196
-25 -32 196,358
-20 -29 165,180
-15 -26 139,402
-10 -23 118,018
-5 -21 100,221
0 -18 85,362
5 -15 72,918
10 -12 62,465
15 -9 53,658
20 -7 46,218
25 -4 39,913
30 -1 34,558
35 2 29,996
40 4 26,099
45 7 22,763
50 10 19,900
55 13 17,436
60 16 15,311
65 18 13,474
70 21 11,883
75 24 10,501
80 27 9,299
85 29 8,250
Temperature Resistance
°F °C Ω
90 32 7,334
95 35 6,532
100 38 5,828
105 41 5,210
110 43 4,665
115 46 4,184
120 49 3,760
125 52 3,383
130 54 3,050
135 57 2,754
140 60 2,490
145 63 2,255
150 66 2,045
155 68 1,857
160 71 1,689
165 74 1,538
170 77 1,403
175 79 1,281
180 82 1,172
185 85 1,073
190 88 983
195 91 903
200 93 829
205 96 763
210 99 703
215 102 648
220 104 598
225 107 553
