Upright SB60 - BASIC ASSEMBLY, SB60

Illustrated Parts Breakdown
Section
SB60 Work Platform6-10
6.2
BASIC ASSEMBLY, SB60
100004-000 - GAS
100004-001 - DIESEL
ITEM PART DESCRIPTION QTY.
1 100008-000 CHASSIS ASSEMBLY 1
2 100010-000 TURRET ASSEMBLY 1
3 100009-000 LIFT BOOM ASSEMBLY 1
4 100011-000 JIB BOOM ASSEMBLY/INSTALLATION 1
5 100120-000 COUNTERWEIGHT 1
11 100013-000 ENGINE MODULE ASSY, (GAS) 1
12 100012-000 ENGINE MODULE ASSY, (DSL) 1
13 100555-000 LIFT CYLINDER 1
* 100555-010 SEAL KIT 1
14 100553-000 MASTER CYLINDER 1
* 100553-010 SEAL KIT 1
15 100474-002 PIN, (LIFT CYL. BASE END) 1
16 100474-001 PIN, (LIFT CYL. ROD END) 1
17 100472-002 PIN, (MASTER CYL. BASE END) 1
18 100472-001 PIN, (MASTER CYL. ROD END) 1
21 100474-000 PIN, (BOOM PIVOT) 1
22 100054-000 COVER, CHASSIS FRONT 1
23 100055-000 COVER, CHASSIS REAR 1
24 100472-010 PIN, ENGINE MODULE 1
25 011254-004 SCREW, HHC 3/8-16 UNC X 1/2 8
26 011238-006 WASHER, SPLIT LOCK 3/8 6
27 011254-007 SCREW, HHC GRS 3/8-16 UNC X 7/8 LG 6
28 014252-006 NUT-SERT 3/8-16 UNC. 3
29 010092-011 THRUST WASHER 3
30 011934-004 FITTING, 90° 6MB-6MJ 2
31 020733-002 FITTING, TEE 6FJ-6MJ-6MJ 1
32 011941-005 FITTING, STR. 6MB-6MJ 1
33 011934-001 FITTING, 90° 4MB-4MJ 1
34 011941-001 FITTING, STR. 4MB-4MJ 1
35 011238-016 WASHER, SPLIT LOCK 1" DIA 4
36 014918-024 SCREW, HHC 1-8 UNC X 3" 2
37 014918-032 SCREW, HHC 1-8 UNC X 4" 2
38 014996-006 WASHER 3/8" DIA. FLAT 8
39 011240-006 WASHER, FLAT STD 3/8 8
40 100561-000 HYD. TUBE, LIFT CYLINDER 1
41 065396-099 HOSE GUARD (1.42 ID) FT 5
42 100385-099 HOSE GUARD (2.88 ID) FT 3.5
43 011257-012 SCREW, HHC 5/8-11 UNC X 1-1/2 4
44 011238-010 WASHER SPLIT LOCK 5/8 4
45 014996-010 WASHER 5/8 SAE FLAT PLTD 4
46 011291-024 SCREW, HHC GR8 5/8-11 UNC X 3" LG 20
47 100191-010 WASHER, 5/8 DIA. ASTM A-525 20
48
100014-000 CONTROL MODULE ASSY, (GAS) 1
100014-001 CONTROL MODULE ASSY, (DSL) 1
49 100198-000 SHIM - COUNTERWEIGHT 4
50 019930-252 BALLAST PLATE 1
