Illustrated Parts Breakdown
Section
SB60 Work Platform 6-11
6.2
41
ROUTE MSTR CYL.
HOSES THRU.
LOCATE IN TURRET
42"LG
42
29
26
27
ROUTE EXT. CYL.
HOSES THRU.
30"LG
ROUTE SLAVE CYL.
HOSES THRU.LOCATE
UNDER TIP BOOM
18"LG
41
ROUTE JIB
HOSES THRU
12"L
41
27
26
21
26
39 38 25
45 44 43
22
35
36
27
26
27
26
27
26
16
24
17
33
34 14
31
30
18
15
5
12 11
28
3
30
47
46
1
23
48
1
BLUE LOCTITE #242 - 190 LBS TORQUE
13
32
40
COUNTERWEIGHT ITEM #5 IS TO BE MOUNTED
SUCH THAT THIS SURFACE IS VERTICAL WITHIN
± 1/2° - ADJUST USING SHIM ITEM #49
ADD OR SUBTRACT ITEM #50 AS REQUIRED TO MAKE
TOTAL WEIGHT OF ITEM #5 AND 50 - 3170 ±63LBS.
2
49
2
50
SEE NOTE 2
