Illustrated Parts Breakdown
Section
SB60 Work Platform6-12
6.2
CHASSIS ASSEMBLY, SB60
100008-000
ITEM PART DESCRIPTION QTY.
1 100030-000 WELDMENT, CHASSIS 1
2 100060-000 ASSEMBLY, STEERING AXLE 1
3 100090-001 ASSEMBLY, TIRE & WHEEL RH 2
4 100472-009 PIN, BOOM PIVOT 4
5 100473-000 PIN, BOOM PIVOT 1
6 100556-000 AXLE LOCK CYLINDER 2
* 100556-010 SEAL KIT 1
7 100563-000 THRUST WASHER 2-1/2 IN ID 2
8 100249-000 DRIVE MOTOR 4
* 100249-010 SEAL KIT 1
9 100254-000 DRIVE HUB 4
* 100254-010 SEAL KIT W/BEARING 1
* 100254-020 SERVICE KIT 1
10 100244-000 SLEW BEARING 1
11 011256-010 SCREW 1/2-13 UNC HHC X 1-1/4 LG 1
12 011238-008 WASHER SPLIT LOCK 1/2 1
13 011254-004 SCREW 3/8-16 UNC HHC X 1/2 LG 4
14 011238-006 WASHER SPLIT LOCK 3/8 4
15 011469-006 LUG NUT 5/8-11 UNF 36
16 011291-020 SCREW 5/8-11 UNF HHC GR 8 X 2-1/2 LG 20
17 011239-010 WASHER FLAT ASTM A325 5/8 20
18 100434-002 FITTING 4MFFOR-4MB 90° 6
19 011937-001 FITTING 4FJX-4MJ 90° 4
21 011935-005 FITTING 10MB-8MJ 45° 4
22 068812-000 FLANGE KIT 12SFXO 8
23 100433-001 FITTING 4MFFOR-4MB 45° 2
24 100090-000 ASSEMBLY, TIRE & WHEEL LH 2
25 011941-001 FITTING, STR. 4MB-4MJ 2
26 100317-000 VALVE BLOCK ASSY DIFF LOC 1
28 014252-006 NUT SERT 3/8-16 UNC 8
30 100716-000 VALVE BLOCK ASSY, FRONT DRIVE CHECKS 1
31 100717-000 VALVE BLOCK ASSY, REAR DRIVE CHECKS 1
34 011257-016 SCREW 5/8-11 UNC HHC X 2 LG 24
35 011238-010 WASHER SPLIT LOCK 5/8 24
36 011296-010 SCREW 1/2-13 SOC HD CAP X 1-1/4 8
37 011238-008 WASHER SPLIT LOCK 1/2 8
38 011239-008 WASHER FLAT ASTM A325 1/2 8
41 061796-099 GROMMET FT 2.5
42 100385-099 HOSE GUARD (2.88 ID) FT 5
43 065369-099 HOSE GUARD (1.42 ID) 6
44 100388-000 GASKET, WHEEL MOTOR PER PRINT 4
