Illustrated Parts Breakdown
Section
SB60 Work Platform6-14
6.2
TURRET ASSEMBLY
100010-000
ITEM PART DESCRIPTION QTY.
1 100150-000 TURRET, MACHINED 1
2 100190-000 ROTARY MANIFOLD ASSEMBLY 1
3 100242-000 SWING GEAR BOX 1
* 100242-011 GASKET 1
4 100241-000 MOTOR 1
* 100241-010 SEAL KIT 1
5 100267-000 VALVE MOUNT BRACKET 2
6 100264-000 CONTROL VALVE BLOCK ASSEMBLY 1
7 100266-000 MOUNT, VALVE BLOCK 1
8 100261-000 MOTOR VALVE BLOCK 1
9 011424-020
SCREW SOC HD CAP 5/8-11 UNC
GR8 X 2-1/2
8
10 011238-101 WASHER SPLIT LOCK 5/8 2
11 100391-010 WASHER EXTRA THICK 5/8 8
12 011248-008 LOCKNUT, 1/2-13 UNC ESNA 4
13 011238-008 WASHER SPLIT LOCK 1/2 8
14 011256-008 SCREW HHC 1/2-13 UNC X 1 4
15 011253-006 SCREW HHC 5/16-18 UNC X 3/4 LG 1
16 011253-014 SCREW HHC 5/16-18 UNC X 1-3/4 2
17 063783-003 LANYARD ASSY X 12" 1
18 011941-009 FITTING 8MB-6MJ 2
19 011940-004 FITTING 90° 4MB-4MJ 2
20 100374-000 GUARD PANEL 1
21 100376-000 GUARD PANEL 1
22 100371-000 GUARD PANEL 1
23 100373-000 GUARD PANEL 1
24 100133-000 LATCH BRACKET WELDMENT 2
25 011254-010 SCREW HHC 3/8-16 UNC X 1-1/4 24
26 100365-000 MOUNTING PLATE WELDMENT 1
27 100360-000 MOUNTING PLATE WELDMENT 1
28 100356-000 PIVOT WLEDMENT 2
29 100277-000 SLEW LOCK WELDMENT 1
30 100278-000 PIN, SLEW LOCK 1
31 100595-007 LOCKING PIN 1
32 011256-020 SCREW HHC 1/2-13 UNC X 2-1/2 4
33 011707-024 SCREW, SET HEX SOC 1/2-13 UNC X 3 2
ITEM PART DESCRIPTION QTY.
34 011273-008 NUT, HEX JAM 1/2-13 UNC 6
35 100390-000 WELDMENT, GUIDE 2
36 REF PROXIMITY SWITCH REF
37 014996-006 WASHER, 0-3/8 FLAT STEEL 20
38 011253-006 SCREW, HHC 5/16-18 UNC X 3/4 5
39 011238-006 LOCKWASHER, 0-3/8 SPLIT RING 16
40 011254-008 SCREW, HHC 3/8-16 UNC X 1 16
41 011248-006 LOCKNUT, 3/8-16 UNC ESNA 16
42 011253-008 SCREW, HHC 5/16-18 UNC X 1 2
43 011240-005 WASHER 5/15 FLAT 21
44 100378-000 COVER 1
45 011253-012 SCREW HHC 5/8-11 UNC X 1-1/2 2
46 008942-001 COVER, RECEPTACLE 1
47 029961-000 INLET, MALE 1
48 029961-001 SEAL 1
49 011709-006 SCREW, RD. HD. #6-32 X 3/4 4
50 011248-047 LOCKNUT, HEX #6-32 ESNA 4
51 019928-213 GUSSET 2
52 019930-252 BALLAST PLATE 1/2" REF
53 019936-035 BALLAST PLATE 1" 4
54 100066-001 SHIM, SLEW DRIVE 1
55 100379-000 GUARD, SLEW PINION-EURO ONLY REF
56 011238-005 WASHER, SPLIT LOCK 5/16 7
57 011297-010 WASHER, BELLVILLE 5/8 8
58 011248-005 LOCKNUT, 5/16-18 UNC ESNA 6
59 011253-020 SCREW HHC 5/16-18 UNC X 2-1/2 8
60 011256-028 SCREW HHC 1/2-13 UNC X 3-1/2 4
61 029958-001 HORN 12 VOLT 1
62 013919-012 CLAMP 4
63 100384-008 SET SCREW 5/8-11 X 1 LG CUP POINT REF
64 011273-010 JAM NUT 5/8-11 REF
65 100386-099 HOSE GUARD FT 4
