Illustrated Parts Breakdown
Section
SB60 Work Platform6-22
6.2
ENGINE MODULE ASSEMBLY, SB60
DIESEL
100012-000
ITEM PART DESCRIPTION QTY.
1 100180-000 ENGINE, PERKINS DIESEL 1
2 100168-000 ENGINE MODULE WELDMENT 1
3 100248-000 PUMP, REXROTH 1
* 068668-005 SOLENOID 2
* 100248-010 SEAL KIT 1
4 100715-000 PUMP, BARNES 1
5 100214-000 BRACKET, FILTER MOUNT 1
6 100185-000 BRACKET, MUFFLER/AIR CLEANER MOUNT 1
7 100562-150 BUSHING, GARLOCK 1-1/2 X 2 2
8 100210-000 BATTERY TRAY WELDMENT 1
9 062299-002 BATTERY, 12 VOLT 1
10 100323-000
VALVE BLOCK ASSY, BRAKE,
1
AXLE LOCK, 2-SPEED
11 014693-002 FITTING REDUCER 8FJ-4MJ 1
12 100289-000 FILTER 1
* 100289-010 FILTER ONLY 1
13 100209-000 ENGINE MOUNT, ISOLATOR 4
14 068812-000 FLANGE KIT, 12SFXO 2
15 011934-019 FITTING, 90° ADAPTER 16MB-16MJ 1
16 011934-013 FITTING, 90° ADAPTER 12MB-8MJ 3
17 100433-001 FITTING, 45° ADAPTER 4MFFOR-4MB 1
18 100434-002 FITTING, 90° ADAPTER 4MFFOR-4MB 1
19 011941-010 FITTING, STR ADAPTER 8MB-8MJ 2
20 020733-003 FITTING, TEE ADAPTER 8FJX-8MJ-8MJ 3
21 011941-004 FITTING, STR ADAPTER 10MB-8MJ 1
22 011937-004 FITTING, 90° ADAPTER 8FJX-8MJ 1
23 011935-006 FITTING, 45° ADAPTER 10MB-10MJ 1
25 010150-005 FITTING BULKHEAD 8MJ-8MJ 1
26 013487-001 FITTING, STR ADAPTER 2MP-2MP 1
27 011915-001 FITTING, TEE ADAPTOR 2FP-2FP-2FP 1
28 068954-001 OIL PRESSURE SWITCH 1
29 100333-000 OIL PRESSURE SENDING UNIT 1
30 011238-006 LOCKWASHER, 3/8" SPLIT RING 2
31 011254-008 SCREW, HHC 3/8-16 X 1 2
32 014996-008 WASHER, 1/2" FLAT 2
33 011238-008 LOCKWASHER, 1/2" SPLIT RING 4
34 011256-012 SCREW, HHC 1/2-13 X 1-1/2 2
35 011252-008 SCREW, HHC 1/4-20 X 1 2
36 014996-004 WASHER, 1/4" FLAT 18
37 011248-004 LOCKNUT, 1/4-20 UNC ESNA 18
38 011253-008 SCREW, HHC 5/16-18 X 1 2
39 011248-005 LOCKNUT, 5/16-18 UNC ESNA 10
40 011253-006 SCREW, HHC 5/16-18 X 3/4 4
41 011252-006 SCREW, HHC 1/4-20 X 3/4 20
42 011238-004 LOCKWASHER, 1/4" SPLIT RING 2
43 011254-024 SCREW, HHC 3/8-16 UNC X 3-1/2 4
NOTE: Items 51-64 supplied with
item 1, engine PN 100180-000
ITEM PART DESCRIPTION QTY.
44 011248-006 LOCKNUT 3/8-16 UNC ESNA 8
45 012039-000 J-BOLT, BATTERY HOLD-DOWN 2
46 064040-000 BATTERY HOLD-DOWN BAR 1
47 011252-022 SCREW, HHC 1/4-20 X 2-3/4 2
48 011254-006 SCREW, HHC 3/8-16 X 3/4 8
49 011253-007 SCREW, HHC 5/16-18 UNC X 7/8 4
50 011456-020 SCREW, HHC M12 X 1.75 X 20MM 2
51 100180-030 AIR CLEANER
52 * CLAMP, AIR CLEANER
53 * RAIN CAP
54 100180-032 MUFFLER
55 * CLAMP, MUFFLER
56 * OVER-FLOW BOTTLE
57 * BRACKET, OVER-FLOW
58 * THROTTLE CONTROL
59 * SPLINED COUPLER
60 * GASKET, EXHAUST FLANGE
61 * NUT, EXHAUST FLANGE
62 100180-034 EXHAUST PIPE
63 * EXHAUST CLAMP
64 * HOSE, AIR INTAKE
66 067672-020 SCREW, HHC M8 X 1/25 X 20MM 4
67 011238-005 LOCKWASHER, 5/16" SPLIT RING 4
69 020541-024 HOSE CLAMP GATES #48 2
71 011934-020 FITTING, 90° ADAPTER 16MB-20MJ 1
72 068565-001 ACCUMULATOR (125 PSI) 1
73 100192-000 WASHER, SNUBBER 4
74 100318-000
MOUNTING BRACKET, ENGINE
THROTTLE CONTROL
2
75 100332-000 SENDING UNIT, TEMP. 1
76 100324-000 POWER CONVERTER 1
77 012865-099 WIRE LOOM 3/4" FT 30
78 027972-000 SOLENOID, START 12 VOLT 2
79 011922-006 FITTING, STR. ADAPTER 6MP-8FP 1
80 017305-099 TUBE, 1/4 OD X 20 GA STEEL FT .17
81 017303-099 TUBE, 5/16 OD X 20 GA STEEL FT .17
82 020541-003 HOSE CLAMP GATES #6 4
83 012739-099 HOSE, 1/4 FUEL LINE FT 18
84 012733-099 HOSE, 5/16 FUEL LINE FT 18
85 063947-005 NUT, 5MM 1
86 063947-007 NUT, 7MM 1
* Not shown
