Upright SB60 - Page 115

Illustrated Parts Breakdown
Section
SB60 Work Platform 6-23
6.2
ENGINE MODULE ASSEMBLY, SB60
DIESEL
100012-000
ITEM PART DESCRIPTION QTY.
201 100338-000 CONNECTOR, MALE (21 PIN) 1
202 100338-005 BOOT 1
205 100338-012 CONTACT, 12 GA SOCKET 3
207 100338-014 CONTACT, 16 GA SOCKET 15
209 068764-000 PLUG, SEALING 3
210 029480-099 WIRE, 10 GA RED FT 6
211 029484-099 WIRE, 8 GA RED FT 6
212 029452-099 WIRE, 16 GA BLACK FT 6
213 029451-099 WIRE, 16 GA WHITE FT 6
214 029454-099 WIRE, 16 GA RED FT 6
215 029457-099 WIRE, 16 GA GREEN FT 6
216 029453-099 WIRE, 16 GA ORANGE FT 6
217 029450-099 WIRE, 16 GA BLUE FT 6
218 029479-099 WIRE, 16 GA WHITE/BLACK FT 6
219 029478-099 WIRE, 16 GA RED/BLACK FT 6
220 005491-099 WIRE, 16 GA GREEN/BLACK FT 6
221 029477-099 WIRE, 16 GA ORANGE/BLACK FT 6
222 029475-099 WIRE, 16 GA BLUE/BLACK FT 6
223 029351-099 WIRE, 16 GA BLACK/WHITE FT 6
224 029352-099 WIRE, 16 GA RED/WHITE FT 6
225 029353-099 WIRE, 16 GA GREEN/WHITE FT 6
226 029354-099 WIRE, 16 GA BLUE/WHITE FT 6
227 029470-099 WIRE, 12 GA RED FT 6
228 064195-080 BATTERY CABLE ASSY X 80 LG 1
229 064195-050 BATTERY CABLE ASSY X 50 LG 1
230 029931-003 CONN FEM PUSH (.25) 16-14 GA 7
231 029617-002 CONN MALE PUSH (.25) 16-14 GA 6
232 029601-039 CONN RING TERM 0-5/16 12-10 GA 8
233 029601-012 CONN RING TERM. #8 0 16-14 GA 2
234 029620-003 CONNECTOR, BUTT 10-12 GA 3
235 029610-006 CONN FORK TERM #8 0 14-16 GA 4
236 029825-002 DIODE, 5 AMP 1
237 014435-001 BATTERY TERMINAL 2
238 029601-025 CONN RING TERM 0 5/16 8 GA 4
239 064195-032 BATTERY CABLE ASSY X 32 LG 1
240 029419-099 WIRE, 12 GA RED. GRN 6
241 029418-099 WIRE, 12 GA RED/BLK 12
ENGINE REPAIR PARTS
SB60, DIESEL
ITEM PART DESCRIPTION QTY.
* 100180-005 OIL FILTER 1
* 100180-006 FUEL FILTER 1
* 100180-007 FAN BELT 1
* 100180-008 INJECTOR 1
* 100180-009 STARTER 1
* 100180-010 STARTER SOLENOID 1
* 100180-011 ALTERNATOR 1
* 100180-012 ALTERNATOR BRACKET 1
* 100180-013 WATER PUMP 1
* 100180-014 WATER HOSE TOP 1
* 100180-015 WATER HOSE BOTTOM 1
* 100180-016 THERMOSTAT 1
* 100180-017 STARTER SOLENOID 1
* 100180-018 INJECTOR LINE 1
* 100180-019 INJECTOR LINE 1
* 100180-020 INJECTOR LINE 1
* 100180-021 INJECTOR LINE 1
* 100180-022 WATER HOSE BOTTOM 1
* 100180-023 THROTTLE LINK 1
* 100180-024 OIL DRAIN PLUG 1
* 100180-025 OIL DRAIN WASHER 1
* 100180-026 INT. MAIN GASKET 1
* 100180-027 EXHAUST MANIFOLD GASKET 1
* 100180-028 HEAD GASKET 1
* 100180-029 ALTERNATOR BRACKET 2 1
* 100180-030 AIR CLEANER 1
* 100180-031 THROTTLE CONTROL 1
* 100180-032 MUFFLER 1
* 100180-033 EXHAUST FLANGE 1
* 100180-034 EXHAUST PIPE 1
* 100180-035 EXHAUST FLANGE 1
* 100180-036 FLYWHEEL FLANGE 1
* 100180-037 THROTTLE ACTUATOR 1
