Illustrated Parts Breakdown
Section
SB60 Work Platform 6-63
6.2
JIB BOOM
(VALVE BLOCK ASSEMBLY)
100283-001
ITEM PART DESCRIPTION QTY.
1 100283-000 VALVE BLOCK, SH #9S002011-A 1
2 012004-006 PLUG, HOLLOW HEX #6 SAE 1
3 011941-004 FITTING, STR. ADAPTOR 6MB-4MJ 4
4 011935-013 FITTING, 45° 6MB-4MJ 2
5 100283-011 COIL, SOLENOID 2
