Upright SB60 - ROTARY MANIFOLD ASSEMBLY

Illustrated Parts Breakdown
Section
SB60 Work Platform6-64
6.2
ROTARY MANIFOLD ASSEMBLY
100190-000
ITEM PART DESCRIPTION QTY.
1 100558-000 ROTARY MANIFOLD 1
2 015961-006 FITTING 6MJ-6MB TEE 2
3 011935-003 FITTING 6MB-6MJ 45° ELBOW 4
4 011937-003 FITTING 6MJ-6FJX 90° ELBOW 2
5 100433-016 FITTING 12MFFOR-16MB 45° ELBOW 2
6 015736-003 FITTING 8MB-8MJ 90° ELBOW 1
7 011941-010 FITTING 8MB-8MJ STRAIGHT 2
8 100434-023 FITTING 12MFFOR-16MB 90° 1
9 014693-001 FITTING 6FJX-4MJ STRAIGHT 2
10 100432-027 FITTING 12MB-12MFFOR STRAIGHT 2
11 100435-001 FITTING 4MFFOR - 90° 1
12 100433-002 FITTING 4MFFOR-6MB 45° 5
14 100382-000 TORQUE ARM 1
15 011253-008 SCREW HHC 5/16-18 UNC X 1 LG 2
16 011238-005 WASHER 5/16 LOCK 2
17 011248-005 NUT 5/16-18 ESNA 2
18 011941-005 FITTING STR 6MB-6MJ 1
19 011932-003 FITTING STR 6MB-6MJ 1
