Upright SB60 - SIX FOOT CAGE ASSEMBLY

Illustrated Parts Breakdown
Section
SB60 Work Platform 6-71
6.2
SIX FOOT CAGE ASSEMBLY
100417-000
ITEM PART DESCRIPTION QTY.
1 100450-001 CAGE WELDMENT 1
2 100478-000 LIFT-GATE WELDMENT 1
3 100481-000 ROLLER TUBE 2
4 11253-022 SCREW, HHC. 5/16-18 UNC X 2 3/4 2
5 11248-005 LOCKNUT, HEX. 5/16-18 UNC ESNA 2
6 100468-000 PANEL, DECAL MOUNT 1
7 26551-005 POP RIVET, 1/8" DIA. (3/16-1/4 GRIP) 3
