Upright SB60 - EIGHT FOOT CAGE OPTION

Illustrated Parts Breakdown
Section
SB60 Work Platform6-72
6.2
EIGHT FOOT CAGE OPTION
100417-001
ITEM PART DESCRIPTION QTY.
1 100451-001 CAGE WELDMENT (8 FT) 1
2 100478-000 LIFT-GATE WELDMENT 1
3 100481-000 ROLLER TUBE 2
4 011253-022 SCREW, HHC 5/16-18 UNC X 2-3/4 2
5 011248-005 LOCKNUT, HEX 5/16-18 UNC ESNA 2
6 100468-000 PANEL, DECAL MOUNT 1
7 026551-005 POP RIVET, 1/8" DIA. (3/1601/4 GRIP) 3
6
1
3
5
4
2
7
NOTE: LINE DRILL FOR RIVETS AT ASSY.
