Upright SB60 - Page 85

Schematics
Section
SB60 5-35
Upper Controller Assembly
Gas, SB60
100017-000
ITEM PART DESCRIPTION QTY.
201 100309-000 UPPER CONTROL BOX REF
202 029925-002 CONNECTOR CABLE 1/2 NPT 2
203 029939-002 LOCKNUT 1/2 NPT 2
204 100334-000 SWITCH, LEVER 1
205 067893-000 MOUNTING RAIL DIN X 13 LG 1
206 067660-006 TERMINAL END 2
207 067661-001 RELAY SPDT 12 VDC 5
208 067661-004 RELAY 4PDT 12 VDC 1
209 068698-001 TERMINAL BLOCK (TAN) 23
210 068698-000 TERMINAL BLOCK (ORANGE) 2
211 068698-004 END CAP, CONTACT BLOCK 1
212 067662-001 RELAY SOCKET SPDT 5
213 067662-004 RELAY SOCKET 4PDT 1
214 067662-005 RETAINER CLIP ASSY 5
215 067662-007 RETAINER CLIP ASSY 1
216 015790-006 CONNECTOR RECEPTACLE 1
217 015790-004 PIN CONTACT 16-18G 27
218 015790-007 PIN CONTACT 14-16G 3
219 066807-001 ALARM 107DB 1
220 100319-000 HINGE SOUTHCO C6-30 2
221 026553-004 RIVET PDP 3/16 DIA X .375 GRIP 8
222 011240-002 WASHER #8 FLAT 8
223 068698-002 TERMINAL BLOCK (BLUE) 2
224 011715-006 SCREW RD HD MACHINE #6-32 X 3/4 LG 6
225 011240-001 WASHER #6-32 12
226 011248-047 LOCKNUT #6-32 6
227 100337-099 O-RING CORD 3/16 FT 3.5
229 068773-002 JUMPER, 2 PIN 4
230 100707-000 INNER STIFFENER 1
231 100708-000 OUTER STIFFENER 1
232 011252-006 SCREW 1/4-20 UNC HHC X 3/4 LG 1
233 011240-004 WASHER 1/4 FLAT 2
234 011248-004 LOCKNUT 1/4-20 UNC 1
SEE NEXT PAGE
5.9
