Upright SB60 - Page 86

Schematics
Section
SB605-36
Upper Controller Assembly
Gas, SB60
100017-000
ITEM PART DESCRIPTION QTY.
301 029452-099 WIRE, 16 GA BLACK FT 10
302 029451-099 WIRE, 16 GA WHITE FT 10
303 029454-099 WIRE, 16 GA RED FT 10
304 029457-099 WIRE, 16 GA GREEN FT 10
305 029450-099 WIRE, 16 GA BLUE FT 10
306 029479-099 WIRE, 16 GA WHITE/BLACK FT 10
307 029478-099 WIRE, 16 GA RED/BLACK FT 10
308 005491-000 WIRE, 16 GA GREEN/BLACK FT 10
309 029351-099 WIRE, 16 GA BLACK/WHITE FT 10
310 029352-099 WIRE, 16 GA RED/WHITE FT 10
311 029353-099 WIRE, 16 GA GREEN/WHITE FT 10
312 029354-099 WIRE, 16 GA BLUE/WHITE FT 10
313 029355-099 WIRE, 16 GA BLACK/RED FT 10
314 029358-099 WIRE, 16 GA BLUE/RED FT 10
315 029356-099 WIRE, 16 GA WHITE/RED FT 10
316 029360-099 WIRE, 16 GA ORANGE/GREEN FT 10
317 029456-099 WIRE, 16 GA YELLOW FT 10
318 029477-099 WIRE, 16 GA ORANGE/BLACK FT 10
319 029475-099 WIRE, 16 GA BLUE/BLACK FT 10
320 029359-099 WIRE, 16 GA RED/GREEN FT 10
321 029455-099 WIRE, 16 GA BROWN FT 10
322 029362-099 WIRE, 16 GA RED/BLACK/WHITE FT 10
323 029453-099 WIRE, 16 GA ORANGE FT 10
324 029488-099 WIRE, 16 GA, 6 COND FT 11
325 029461-099 WIRE, 14 GA BLACK FT 10
326 029466-099 WIRE, 14 GA WHITE FT 10
327 029460-099 WIRE, 14 GA RED FT 10
328 029825-002 DIODE, 5 AMP, 400V 15
329 029601-013 CONN, RING 16-14 #10 23
330 029610-006 CONN, FORK 16-14 #6 59
331 029616-002 CONN, FEMALE PUSH 16-14 4
332 029490-099 WIRE 16 GAUGE, 2 COND, TYPE SO FT 5
5.9
