Page 9SL20
MAXIMUM DISTRIBUTED
PLATFORM LOAD 750 LBS.
OR 2 OCCUPANTS
MAXIMUM SIDE LOAD 113 LBS.
9
CIRCUIT
BREAKER
MAX
FILLLINE
MIN
1775 PARK ST. SELMA CALIFORNIA 93662 USA
Model:______________
Serial number:_____________
GVW: __________lbs.
Mfg. date:___________
Occupants and equipment must not exceed the rated workload
_____lbs. Rated number of occupants: _____
Maximum platform height: ______ft.
Nominal system voltage: ______vdc
Maximum wheel and/or outrigger load: _____lbs.
This machine is manufactured to comply with ANSI A92.6-1999.
CAUTION: CONSULT OPERATOR’S MANUAL BEFORE USE.
THIS PLATFORM IS NOT ELECTRICALLY INSULATED
LOADING CLEARANCE
LOWERING SWITCH
TIP-OVER HAZARD
MAXIMUM DISTRIBUTED LOAD
250 LBS. OR 1 OCCUPANT
MAXIMUM SIDE LOAD 100 LBS
061205-005
1 required
066568-000
1 required
101203-000
1 required
014222-003-99
2 required
066556-001
4 required
066559-000
1 required
066552-000
1 required
005221-000
1 required
062562-001
1 required
066553-004
2 required
061220-002
1 required
101250-002
2 required
066550-006
1 required
066554-000
1 required
010076-001
1 required
101251-000
1 required
066558-000
1 required
066555-000
1 required
066553-001
2 required
MAXIMUM
WHEEL LOAD
1150 LBS
101252-009
1 required
101235-001
1 required
101222-004
1 required
NOTE: Labels can be ordered by using part number
located by each label. For machines equipped with options,
consult the Service Manual
Proper SL20 label installation is required. All of these labels shall be present
and in good condition before operating the work platform. Be sure to read,
understand, and follow these labels when operating the work platform.
