USX-MOUNT XML019-01 - Parts for Step 2; Parts for Step 3

5
Parts and Hardware for STEP 2
Lag Bolt
x4
Wall Plate Unit
x1
Allen Key
x1
Extension Arm
M6x16mm Bolt
x2
M6x8mm Bolt
x4
Extension Arm
x2
x2
End Support
x2
Parts and Hardware for STEP 3
M5x10mm Bolt
x4
Contact us at telephone 1-800-460-0956 (USA) or
message to us to have these additional pieces
shipped directly to you.
Concrete Wall Anchor
4pcs
Velcro x3
Mounting template
R
8"(203.2mm)
16"(406.4mm)
