17
+5°
-15°
Tighten
Loosen
Tilting bolts
6-2 Tilting angle adjustment (+5°/-15°)：
Loosen handle and tilting bolt, adjust TV to your desired position,then tighten handle
and tilting bolt. Put the handle level when finish.
Handle
Tighten
Loosen
05
05
