USX-MOUNT XML032-K - XML032-K说明书_C002

TV INTERFACE
3-D
WALL PLATE TOP VIEW - EXTENDED
Dimensions
144mm
[5.67in]
9mm
[0.35in]
406mm
[16.00in]
382mm
[15.02in]
3
FULLY ASSEMBLED MOUNT TOP VIEW - RETRACTED
SIDE VIEW - EXTENDED
SIDE VIEW - EXTENDED
+45°
178mm
[7.03in]
429mm
[16.90in]
435mm
[17.13in]
67mm
[2.62in]
697mm
[27.42in]
+5°
-15°
MAX:600mm[23.62"]
MIN:200mm[7.87"]
400mm
[15.75in]
MIN: 100mm
[3.94n]
