Utax CLP 3521

2HL/2HM/2HN
2-1-16
Figure 2-1-17 Transfer/separation section block diagram
Engine PWB
High voltage PWB
Left ID sensor
Right
ID sensor
Secondary
transfer rolle
r
Primary
transfer
roller M
Primary
transfer
roller C
Primary
transfer
roller Y
Primary
transfer
roller K
Transfer belt
Cleaning
roller
T2RREMN
Secondary transfer bias output
Primary transfer bias output K
Primary transfer bias output Y
Primary transfer
bias output C
Primary transfer
bias output M
Cleaning bias output
YC16-7
VOSL VOPL
LEDREFL
VOSR VOPR
LEDREFR
YC5-5 YC5-4 YC5-2 YC6-5 YC6-4 YC6-2
CN1-21
CLCNT
YC16-20
CN1-8
T1MCNT
YC16-21
CN1-7
T1CCNT
YC16-22
CN1-6
T1YCNT
YC16-23
CN1-5
T1KCNT
YC16-24
CN1-4
T2CNT
YC16-25
CN1-3
