Utax P-C2160DN User Manual

4-59
Using the Operation Panel
AppleTalk (AppleTalk setting)
AppleTalk is a communications protocol used primarily on Macintosh
computers and also refers to the Mac OS network functions.
AppleTalk assigns 24-bit network addresses (a 16-bit network section and
an 8-bit node address) that are used to identify devices (computers,
printers, etc.) on the network.
When the power is turned on, a broadcast signal is sent out onto the
network and the addresses and machine names are automatically
assigned. The default setting is On.
1 After entering the administrator ID and password, press  or 
repeatedly until >AppleTalk appears.
2 Press [OK]. A blinking question mark (?) appears.
3 Press  or  to select whether AppleTalk is enabled.
4 Press [OK].
5 Press [MENU]. The display returns to Ready.
IPSec (IPSec setting)
IPSec (IP Security Protocol) is a security protocol adopted as the
standard by the IETF for authentication and encryption in the third
network layer (IP layer).
It can be used with both IPv4 and IPv6.
1 After entering the administrator ID and password, press  or 
repeatedly until >IPSec appears.
2 Press [OK]. A blinking question mark (?) appears.
3 Press  or  to select whether IPSec is enabled.
4 Press [OK].
5 Press [MENU]. The display returns to Ready.
LAN Interface (LAN Interface setting)
Specify the settings for the LAN interface to be used. The default setting
is Auto.
1 After entering the administrator ID and password, press  or 
repeatedly until >LAN Interface appears.
>AppleTalk
? On
Note IPv4 uses 32-bit IP addresses and IPv6 uses 128-bit IP
addresses.
>IPSec
? Off
Note LAN Interface is only displayed when the optional network
interface kit (IB-50) is installed.

Utax P-C2160DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	10.5 s
Time to first page (color, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Maximum duty cycle	- pages per month
Number of print cartridges	-
Paper input type	Cassette
Total input capacity	250 sheets
Multi-Purpose tray input capacity	50 sheets
Paper tray media types	Cut sheet
Paper tray media weight	60 - 163 g/m²
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Standard interfaces	USB 2.0
Memory slots	1
Internal memory	512 MB
Processor model	465S
Processor family	PowerPC
Processor frequency	677 MHz
Compatible memory cards	SD
Maximum internal memory	1536 MB
Sound power level (standby)	43 dB
Sound pressure level (printing)	61.7 dB
Certification	GS/TÜV, CE
Product color	Grey, White
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1129 W
Power consumption (off)	0.1 W
Power consumption (standby)	57 W
Power consumption (printing)	360 W
Power consumption (PowerSave)	6 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	523 mm
Width	390 mm
Height	370 mm
Weight	29300 g
