Utax P-C2160DN User Manual

Handling Paper
3-16
5 Align the paper with the paper guides and insert as far as it will go.
6 Set the MP tray paper size on the printer’s operation panel. Refer to
MP Tray Size (Setting MP tray paper size) on page 4-30.
Paper stopper
To use the sheet ejection stopper, open as shown below. (Example:
Legal)
Load
Limit
Load
Limit
Note Do not load more paper than will fit under the load limits
on the inside of the MP tray.
When printing on transparencies, feed the sheets into the
printer one at a time.
If the paper is considerably curled in one direction, for
example, if the paper is already printed on one side, try to roll
the paper in the opposite direction to counteract the curl.
Printed sheets will then come out flat.
Correct
Incorrect

Utax P-C2160DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	10.5 s
Time to first page (color, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Maximum duty cycle	- pages per month
Number of print cartridges	-
Paper input type	Cassette
Total input capacity	250 sheets
Multi-Purpose tray input capacity	50 sheets
Paper tray media types	Cut sheet
Paper tray media weight	60 - 163 g/m²
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Standard interfaces	USB 2.0
Memory slots	1
Internal memory	512 MB
Processor model	465S
Processor family	PowerPC
Processor frequency	677 MHz
Compatible memory cards	SD
Maximum internal memory	1536 MB
Sound power level (standby)	43 dB
Sound pressure level (printing)	61.7 dB
Certification	GS/TÜV, CE
Product color	Grey, White
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1129 W
Power consumption (off)	0.1 W
Power consumption (standby)	57 W
Power consumption (printing)	360 W
Power consumption (PowerSave)	6 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	523 mm
Width	390 mm
Height	370 mm
Weight	29300 g
