Utax P-C2160DN User Manual

6-3
Troubleshooting
Print Quality Problems
The tables and diagrams in the following sections define print quality
problems and the corrective action you can conduct to solve the
problems. Some solutions may require cleaning or replacing parts of the
printer.
If the suggested corrective action will not solve the problem, call for
service.
Printed Results Corrective Action
Skewed-color printout Conduct color registration using the printer operation panel.
For details, refer to Registration Normal (Color registration [standard]) on
page 4-98 or Registration Details (Color registration [detailed]) on page 4-
101.
Completely blank printout Check the toner containers.
Open the printer top cover (top tray) and check that the toner containers
are correctly installed in the printer. For more information on installing the
toner containers, refer to Toner Container Replacement on page 5-2.
Check that the application software is correctly operated.
Dropouts or stray dots Clean the LSU.
For details, refer to LSU (LSU cleaning mode setting) on page 4-108.
Black or white vertical streaks Check the operation panel for toner.
If the Toner low C,M,Y,K message is displayed with color description,
install a new toner kit for the color. To replace the toner container, refer to
Toner Container Replacement on page 5-2.
Clean the LSU.
For details, refer to LSU (LSU cleaning mode setting) on page 4-108.
Refresh drum.
For details, refer to Drum (Drum/Refresh mode setting) on page 4-108
Direction
of Paper
Feed

Utax P-C2160DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	10.5 s
Time to first page (color, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Maximum duty cycle	- pages per month
Number of print cartridges	-
Paper input type	Cassette
Total input capacity	250 sheets
Multi-Purpose tray input capacity	50 sheets
Paper tray media types	Cut sheet
Paper tray media weight	60 - 163 g/m²
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Standard interfaces	USB 2.0
Memory slots	1
Internal memory	512 MB
Processor model	465S
Processor family	PowerPC
Processor frequency	677 MHz
Compatible memory cards	SD
Maximum internal memory	1536 MB
Sound power level (standby)	43 dB
Sound pressure level (printing)	61.7 dB
Certification	GS/TÜV, CE
Product color	Grey, White
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1129 W
Power consumption (off)	0.1 W
Power consumption (standby)	57 W
Power consumption (printing)	360 W
Power consumption (PowerSave)	6 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	523 mm
Width	390 mm
Height	370 mm
Weight	29300 g
