Utax P-C2160DN User Manual

4-67
Using the Operation Panel
RAM Disk Mode (Using the RAM disk)
The RAM disk is a memory space shared within the printer memory that
can temporarily store print jobs. The stored print job can then be used to
print multiple copies of the job reducing the total amount of time required
to print the whole job. It acts similar to the SSD except that the data is
effective only when the printer is powered up.
To use the RAM disk, activate and enter the desired size of the RAM disk
in the manner described below. The maximum RAM disk size can be
calculated as follows:
When the RAM disk is activated = The maximum RAM disk size is 32 MB
(when no options are attached)
When the optional memory is installed = The maximum RAM disk size is
1/2 of the total optional memory installed
To activate RAM disk in the printer's memory, first you must set the RAM
disk mode to On and set the desired data size for the RAM disk as
described in the following section. This allows you to perform the
following operations on the RAM disk.
IMPORTANT The RAM disk can not be used when an optional SSD
is installed.
The RAM disk stores data only temporarily. When the printer is reset
or turned off, the stored data will be erased.
The RAM disk allows some Job Box functions to be used.
The RAM disk is allocated from the printer memory available to users.
If the size of the RAM disk is set too large, the printing speed may
decrease or the memory may become insufficient.
1 Press  while Device Common > is displayed.
2 Press  or  repeatedly until >RAM Disk Mode > appears.
3 Press [OK]. A blinking question mark (?) appears.
4 Select On or Off using  or .
5 Press [OK].
6 Press [MENU]. The display returns to Ready.
RAM Disk Size (Setting the RAM disk size)
Use this procedure to set the amount of memory used for the RAM disk.
IMPORTANT The RAM Disk Size menu option only appears when
RAM Disk Mode is set to On.
1 Press  while >RAM Disk Mode On > is displayed.
2 Press [OK]. The message display shows a blinking cursor (_). Press
 or  to display the desired size. Use  and  to move the cursor
right and left.
This range varies depending on the total memory size of the printer.
Note The printer supports two types of storage device; optional
SSD and RAM disk. The optional SSD is installed into the
dedicated slot of the printer. The RAM disk is an allocated part of
the printer’s memory.
>RAM Disk Mode >
? On
>>RAM Disk Size
032
MByte

Utax P-C2160DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	10.5 s
Time to first page (color, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Maximum duty cycle	- pages per month
Number of print cartridges	-
Paper input type	Cassette
Total input capacity	250 sheets
Multi-Purpose tray input capacity	50 sheets
Paper tray media types	Cut sheet
Paper tray media weight	60 - 163 g/m²
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Standard interfaces	USB 2.0
Memory slots	1
Internal memory	512 MB
Processor model	465S
Processor family	PowerPC
Processor frequency	677 MHz
Compatible memory cards	SD
Maximum internal memory	1536 MB
Sound power level (standby)	43 dB
Sound pressure level (printing)	61.7 dB
Certification	GS/TÜV, CE
Product color	Grey, White
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1129 W
Power consumption (off)	0.1 W
Power consumption (standby)	57 W
Power consumption (printing)	360 W
Power consumption (PowerSave)	6 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	523 mm
Width	390 mm
Height	370 mm
Weight	29300 g
