Utax P-C2160DN User Manual

Using the Operation Panel
4-4
Status Information
Error Codes
Refer to the Troubleshooting on page 6-1.
Message Meaning
Self test The printer is performing self-diagnostics after power-up.
Please wait The printer is warming up and is not ready.
When the printer is switched on for the first time, this message will take several minutes.
Please wait
(Paper loading)
This message appears when the printer is preparing to print coated paper (COATED) fed
from the optional paper feeder PF-530.
Please wait
(Adding toner)
Toner is currently being replenished. This message may be displayed during continuous
printing of a large volume of pages which require a large amount of toner such as with
photographs, etc.
Please wait
(Calibrating)
The color calibration function is being performed automatically as you powered on the
printer. You can also execute this function manually on the operation panel.
For details, refer to Color Calibration on page 4-98.
Please wait
(Cleaning)
Displayed during LSU cleaning mode.
Please wait
(Cooling)
The printer is being cooled down and is not ready.
Ready The printer is ready to print.
Processing The printer is receiving data to print. This is also shown when the printer is reading a USB
memory, SSD or RAM disk.
Low power. The printer is in Low Power Mode. The printer wakes from Low Power Mode whenever a
print job is received. The printer then warms up and goes on-line.
For details on Low Power Mode, refer to Low Power Timer (Low Power Mode timer
timeout time) on page 4-72.
Sleeping The printer is in Auto Sleep. The printer wakes from Auto Sleep whenever a print job is
received. The printer then warms up and goes on-line.
For details on Auto Sleep, refer to Sleep Timer (Sleep timer timeout time) on page 4-72.
Canceling data Jobs inside the printer are being canceled. To cancel a job, refer to Canceling a Printing
Job on page 4-6.

Utax P-C2160DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	10.5 s
Time to first page (color, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Maximum duty cycle	- pages per month
Number of print cartridges	-
Paper input type	Cassette
Total input capacity	250 sheets
Multi-Purpose tray input capacity	50 sheets
Paper tray media types	Cut sheet
Paper tray media weight	60 - 163 g/m²
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Standard interfaces	USB 2.0
Memory slots	1
Internal memory	512 MB
Processor model	465S
Processor family	PowerPC
Processor frequency	677 MHz
Compatible memory cards	SD
Maximum internal memory	1536 MB
Sound power level (standby)	43 dB
Sound pressure level (printing)	61.7 dB
Certification	GS/TÜV, CE
Product color	Grey, White
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1129 W
Power consumption (off)	0.1 W
Power consumption (standby)	57 W
Power consumption (printing)	360 W
Power consumption (PowerSave)	6 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	523 mm
Width	390 mm
Height	370 mm
Weight	29300 g
