Utax P-C3570DN - Internal Components; Components at the Rear of the Printer

Machine Parts 1-3
Internal Components
14 Paper Transfer Unit
15 Paper Ramp
16 Duplex Unit
Components at the Rear of the Printer
17 USB Memory Slot
18 Power Cord Connector
19 Option Interface Slot
20 Network Indicators
21 Network Interface Connector
22 USB Interface Connector
23 Rear Cover
17
18 19 20 21
22
23
14
16
15
