Wiegand Interface Unit Four State (WIU-4)

Installation Manual

System requirements

For UL compliant installation notes, refer to “UL Listed Installations”

on page 18

Host software

• Secure Perfect

Edition 3.0 or later

• Picture Perfect

™

1.7 or later

Microcontrollers • Micro/5-PX with 2RP or 8RP

• Micro/5-PXN with 2RP or 8RP

• M5PXNplus

• Micro/PX-2000

• Micro/PXN-2000

• M2000PXNplus

• M3000PXNplus

Reader support • Wiegand data output up to 64 bits

• Most 8 bit keypad reader output formats

Wiegand data

formats

•26-bit

•32-bit

• 35-bit Corporate 1000

•37-bit

• 40-bit formats

• Custom Wiegand formats up to 64 bits
