UTICA BOILERS DVB-125 - Replacement Parts

21
1
2
3
ROLLOUT & SPILL SWITCH
Item # Description Part # Qty.
1
TEMP. SENSOR BRACKET 3262001 1
2
CONTROL-FIXED TEMPERATURE
THERMO (ROLLOUT SWITCH)
AQ02101
1
3
SCREW - #6 X ¼ HEX HD HW06501 2
The rollout switch is located on the base.
NOTE: The quantities above are for each switch.
REPLACEMENT PARTS
PILOT
2
5
1
4
3
SPARK PILOT
Item Part No. Description Qty.
1 109007296 PILOT BRACKET ASSEMBLY 1
2 HW-005.01 BRACKET SCREW 2
3 240007093 SPARK CABLE 1
4 14615005
PILOT TUBING, 1/8" x 24"
1
5
PB-001.02 Natural Gas Q345A PILOT
1
240007096 LP Q345A Pilot
* Included with #3 - Pilot Tube Assembly Kit (above)
