UTICA BOILERS DVB-125 - Page 25

25
PIPING & CONTROLS
ITEM DESCRIPTION P/N QTY.
1 HARNESS IGN/GV 36" 37413601 1
2 HARNESS - CIRCULATOR 72" 37519501 1
3 PIPE - NPL 1¼ X 4½ NPT 1 1310002 1
4 DRAIN - SHORT HW-016.03 1
5 PIPE - TEE 1¼ X ¾ X 1¼ 1510001 1
6 HARNESS- CONTROL/LIMIT 38" 37518901 1
7 GAUGE - THERALTIMETER 1260006 1
8 CONTROL L4080B AQ02201 1
9 WELL ¾" X 3" AQ-020.01 1
10 RELIEF VALVE 30# ¾" VR-001.01 1
11 PIPE - ELBOW ¾" 90° 1190001 1
12 PIPE - NPL ¾" X 4" 1310001 1
3
4
5
7
8
9
10
11
12
6
2
1
REPLACEMENT PARTS
