26
ELECTRICAL
4
5
1
6
8
9
7
2
3
ITEM DESCRIPTION P/N QTY.
1 CONTROL SUPPORT BRACKET 31522201 1
2 PLT SPARK CONTROL 14662070 1
3 WIRE ROLLOUT SWITCH 40" 37614501 1
4 TRANSFORMER - 40VA 550001339 2
5 CONTROL R8222C-1008 (RELAY) 1410001 1
6 9 TERM STRIP EF04001 1
7 SCREW 10-32X5/16 GREEN GROUND HW09001 1
8
PRESSURE SWITCH (FS6205A-2413) 50B - 150B SS00801 1
PRESSURE SWITCH (FS6273A-3065) 200B ONLY SS00802 1
9 HW TUBE SIL ORANGE 1/8ID HW09701 1
FULLY ASSEMBLED CONTROL BRACKET
CONTROL BRACKET SUB-ASSY 50B - 150B 31522901
CONTROL BRACKET SUB-ASSY 200B 31522902
(P/N 31522901 & 31522902 INCLUDE PART # 1-8 & ALL WIRING)
REPLACEMENT PARTS
