UTICA BOILERS DVB-50 - Page 27

27
1
2
5
6
4
3
FLUE COLLECTOR & VENTER COMPONENTS
ITEM DESCRIPTION P/N QTY.
1
FLUE COLLECTOR -50 34524802
1
FLUE COLLECTOR -100 34524804
FLUE COLLECTOR -125 34524805
FLUE COLLECTOR -150 34524806
FLUE COLLECTOR -200 34524808
2
VENT ADAPTER -50, -100, & -125 345-2-7.01
1
VENT ADAPTER -150 & -200 345-2-7.02
3 VENTER MOUNTING PLATE -50 ONLY 34524902 1
4 HW SCR ¼ -20x ½ HW-005.01 5
5 VENTER -50–-200 DC00402 1
6 BOLT
5
⁄
16
"-18 x 1½ 14695039 2
REPLACEMENT PARTS
