B-01286 USLR-XLT Maintenance (11-25-19)
Utility Solutions suggests following the maintenance procedure outlined in this manual every 1,500-
2,000 operations. However, a maintenance schedule should not solely depend on the number of
operations.
Performing operations at or near the maximum amperage rating will result in more degradation, therefore
requiring more frequent maintenance. How and where the tool is stored can also affect the maintenance
schedule. Therefore, 1,500-2,000 operations between routine maintenance is only a benchmark.
! !
WARNING
Carefully read and fully understand this manual prior to
operating, maintaining or testing this device. Improper
operation, handling or maintenance of this device can result
in death, grievous personal injury and or equipment damage.
! !
WARNING
Only trained and qualied personnel should operate, inspect and
maintain this device.
Overview
Required Tools
1/8” Allen Wrench
#2 Phillips Screwdriver
Channel Lock Pliers
6LN Needle Nose Vise Grip
T25 Torx Drive
Required Supplies
All Purpose Very Fine
Nylon Mesh Sanding Pad
Warm Soapy Water
Soft Clean Rag
Required Parts
B-00159
Load Break Tool Fiberglass
Cleaner / Wax (16 oz Container)
B-00856 Loctite
®
425 (20 gram Container)
P-00484
XLT Repair Fastener Kit (2nd Gen)
(Includes all necessary fasteners,
B-01073 Loctite
®
, B-01274 Contact
Grease and C-01080 Split “O”
Ring)
Tools, Parts, and Supplies
Complete Parts List
C-00497 XLT Guide Pin
C-00498 XLT Threaded Pin Plug
C-00507 XLT Stop Bar
C-00509 XLT Arc Shim
C-00513 XLT External Gasket
C-00517 XLT Female Contact
C-00519 XLT Short Conductor Path
C-00520 XLT-1 Long Conductor Path
C-00524 XLT End Cap (Molded)
C-00528 XLT-1 Spacer
C-00539 XLT Extended Hood
C-00541 XLT-2 Long Conductor Path
C-00554 XLT Arc Snuffer
C-00558 XLT-2 Spacer
P-00044 XLT Mufer Cap Assembly
P-00048 XLT-1 Yellow Tube Assembly
P-00049 XLT-1 Probe Shaft Assembly
P-00052 XLT Overhead Arm Assembly
P-00055 XLT Padmount Arm Assembly
P-00323 XLT-1 Black Tub / Can Assembly
P-00822 XLT Counter Assembly
P-00447 XLT-2 Yellow Tube Assembly
P-00449 XLT-2 Probe Shaft Assembly
P-00452 XLT-2 Black Tub / Can Assembly
