3 - INSTALLATION OF THE MOTOR
3.1 - POSITIONING OF THE MOTOR
ToxHYPERFOR,followtheinstructionsbelow:
1. usethemeasurementsindicatedinthedrawingforthe
foundations
2. Arrangeforoneortwopipesforthepassageofelectriccables
3. Assemblethe4clampsontheanchoringplateandxthem
withthe4boltsissuedwiththemotor
4. Pourtheconcreteandpositiontheanchoringplate
m WARNING: check that the plate be on a perfectly
levelled surface and parallel to the gate
5. Waitforthecompletesettingoftheconcrete
6. Unscrewtheboltsxingthebasetotheclampsandputthe
motorontheplate
7. Adjustthe4grainsFtomakethemotorbeperfectlylevelled
8. Controlthatthemotorisperfectlyparalleltothegate,then
insertthe4washersRandlightlyscrewthe4boltsD
50 mm323 mm
20 mm565 mm
10cm
30cm
10cm
F
R
D
